| الاسم التجاري: | GENY |
| رقم الطراز: | YCRT-I370 |
| الـ MOQ: | 1 |
| السعر: | negotiate rates |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T ، Western Union ، Moneygram |
| القدرة على التوريد: | 30 جهاز كمبيوتر شخصي/ 1 شهر |
| Function | Battery internal resistance measurement, battery voltage measurement, temperature measurement |
|---|---|
| Accuracy Conditions | 23℃±5℃, Below 75% RH |
| Power Supply | DC 3.7V lithium battery |
| Resolution | Resistance: 1μΩ | Voltage: 1mV | Temperature: 0.1℃ |
| Measuring Ranges |
Internal resistance: 0.000mΩ~3.100Ω (4 ranges) Voltage: 0.000V~±122.0V (2 ranges) Temperature: -10.0℃~60.0℃ |
| Measurement Method | 1KHz AC 4-terminal test method (3V max open-circuit voltage) |
| Display | 3.5-inch 16-bit true color LCD (320*240 resolution) |
| Connectivity | USB interface and Bluetooth |
| Dimensions | 190mm * 121mm * 51mm |
| Weight | 480g (including battery) |
| Safety Compliance | IEC 61010 |
